Phil Jones Bass PE-5 Preamp, DI Box & 5-band EQ Pedal w/ Rechargeable Battery

Phil Jones Bass PE-5 Preamp, DI Box & 5-band EQ Pedal w/ Rechargeable Battery
Phil Jones Bass PE-5 Preamp, DI Box & 5-band EQ Pedal w/ Rechargeable Battery
Phil Jones Bass PE-5 Preamp, DI Box & 5-band EQ Pedal w/ Rechargeable Battery
Phil Jones Bass PE-5 Preamp, DI Box & 5-band EQ Pedal w/ Rechargeable Battery
$249.99 Excl. tax
In stock
Article number:
PE-5
EAN Code:
812417031269
SKU:
PE-5
Delivery time:
Free 2-Day Shipping (Contiguous US)
Orders placed Mon-Fri by 2pm CST generally ship same day!
  • No Sales Tax

    Orders outside TN
  • Flexible Returns

    14-day trial period
  • Worldwide Shipping

    On most items
  • Complete Setup

    All guitars & basses

Information

Brand New w/ Warranty. We are an authorized Phil Jones Bass dealer.

One pedal to throw in front of any rig. The PE-5 serves as a preamp, a direct box and a signal booster. In addition to a mute switch, you have an engage switch that allows you to bypass or activate your EQ and gain controls, perfect if your “dry” signal is your baseline and you want a particular EQ or boost for a secondary tone. This method works especially well into the front of an amp. Or, use the pedal as an always-on direct box to tailor your tone before sending your signal directly to your sound engineer or recording interface.



What we think:

  • Extremely powerful 5-band EQ
    • Lo-Bass EQ band lets you dial in the sub bass and contours a low B string perfectly
    • Hi-Bass is situated nicely to control any unwanted low frequency buildup in the room
    • Lo- and Hi- Trebles put extra growl or pick attack right at your fingertips
  • Piezo/Magnetic switch changes the impedance at the input to match different instruments
  • ¼” output and pre/post-switchable XLR output provides plenty of flexibility
  • Rechargeable lithium-ion battery means you can leave your power supply at home



We also stock a variety of Phil Jones heads and speaker cabinets. Contact us for bundle pricing!



Specifications



Model: PE-5 Pedal

Input:

  • ¼” Phone
  • Impedance Piezo (“PZ”) = 4.7MΩ
  • Impedance Magnetic (“MG”) = 2MΩ
  • Maximum input before clipping – 4 Volts (peak to peak)

Gain Range: From -6 dB to +6 dB

EQ

  • LO -BASS: Level ±12 dB (Freq. 50Hz)
  • HI-BASS: Level ±15 dB (Freq. 160 Hz)
  • MID: Level ±15 dB (Freq. 630KHz)
  • LO-TREBLE: Level ±15 dB (Freq. 2.5 KHz)
  • HI-TREBLE: Level ±15 dB (Freq. 12 KHz)

Outputs:

  • UNBALANCED 1/4” JACK
  • BALANCED DI OUT with transformer (GND switch)

Controls: GAIN / LEVEL

Switches: Bypass | MUTE | ON/OFF | PRE/POST

Power Requirement: 9VDC - 1A from separate 9volt 1 amp (minimum) adaptor

Dimension (W x D x H): 120 x 95 x 37 mm

Weight: 450 grams
